- General Information
- Manufacturer
- ACTi Corporation
- Manufacturer Website Address
- http://www.acti.com
- Brand Name
- ACTi
- Product Series
- E
- Product Type
- Network Camera
- Warranty
- Limited Warranty
- 3 Year
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/3.2"
- White Balance Modes
- Auto
- Manual
- Hold
- Color Supported
- Color
- Monochrome
- Field of View
- 28.2° to 70.5°
- Effective Camera Resolution
- 3 Megapixel
- Video
- Video Formats
- MJPEG
- H.264
- Maximum Video Resolution
- 2048 x 1536
- Maximum Frame Rate
- 30 fps
- Audio
- Audio Formats
- PCM
- Lens
- Lens Type
- Zoom
- Minimum Focal Length
- 2.80 mm
- Maximum Focal Length
- 12 mm
- Lens Included
- Yes
- Lens Mount Type
- Board Mount
- Maximum Aperture
- f/1.4
- Optical Zoom
- 4.3x
- Focus Modes
- Manual
- Exposure
- Shortest Shutter Speed
- 1/10000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet
- Yes
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP
- UDP
- HTTP
- HTTPS
- DHCP
- PPPoE
- RTP
- RTSP
- IPv6
- DNS
- DDNS
- NTP
- ICMP
- ARP
- IGMP
- SMTP
- FTP
- UPnP
- SNMP
- Bonjour
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Power Description
- Maximum Power Consumption
- 6.49 W
- Physical Characteristics
- Mount Type
- Wall Mount
- Pendant Mount
- Corner Mount
- Pole Mount
- Flush Mount
- Gang Box Mount
- Form Factor
- Dome
- Durability
- Weather Proof
- Vandal Proof
- Height
- 4.6"
- Diameter
- 5.9"
- Weight (Approximate)
- 2.28 lb
- Miscellaneous
- Features
- Day/Night
- Digital Noise Reduction
- SD Card Local Storage
- Privacy Masking
- Motion Detection
- Indoor/Outdoor
- Outdoor
- System Requirements
- Browser:
- Internet Explorer 8.0 or newer
- Safari
- Certifications & Standards
- IP67
- IK10
- CE (EN 55022 Class B, EN 55024)
- FCC (Part15 Subpart B Class B)
- IP66
- NEMA 4X
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP67
- IP66
- Security Features
- IP Address Filtering
- HTTPS Encryption
- Password Protected User Levels
- Anonymous Login
- IEEE 802.1X Network Access Control
- Country of Origin
- Taiwan
