In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-715W/FPM-721W/FPM-724W are industrial-grade, widescreen monitor with sleek, simple lines and a true-flat touchscreen. Equipped with P-CAP 10-point multi-touch control and an IP66-rated front bezel,FPM-715W series is specifically designed for industrial applications. Moreover, FPM-715W/FPM-721W support a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and various mount options to make these monitors ideal for factory and machine automation display applications.
- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Series
- FPM-715W
- Product Type
- LED Touchscreen Monitor
- Technical Information
- Screen Size Class
- 16"
- Viewable Screen Size
- 15.6"
- Screen Mode
- Full HD
- Panel Technology
- Thin Film Transistor (TFT)
- Aspect Ratio
- 16:9
- Horizontal Viewing Angle
- 160°
- Vertical Viewing Angle
- 160°
- Mount Type
- Stand Mountable
- Wall Mountable
- Panel Mount
- Arm-mountable
- Desk Mountable
- Rack-mountable
- Backlight Technology
- LED
- Features
- Anti-glare
- Glass Hardness
- 7H
- Ingress Protection (IP) Rating
- IP66
- Video
- Maximum Resolution
- 1920 x 1080
- Color Supported
- 16.7 Million Colors
- Native Contrast Ratio
- 500:1
- Brightness
- 450 Nit
- Touchscreen Information
- Touchscreen Type
- Projected Capacitive
- Multi-touch Screen
- Yes
- Number of Simultaneous Touchpoints
- 10
- Interfaces/Ports
- HDMI
- Yes
- USB
- Yes
- VGA
- Yes
- DisplayPort
- Yes
- Environmental Conditions
- Operating Temperature Range
- -4°F (-20°C) to 140°F (60°C)
- Power Description
- Maximum Power Consumption
- 12.71 W
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 75 x 75
- Height
- 10.6"
- Width
- 16.5"
- Depth
- 2"
- Weight (Approximate)
- 8.82 lb
- Miscellaneous
- Package Contents
- FPM-715W-P9AE Touchscreen LED Monitor
- 1 x Terminal Block
- 10 x Clamper
- 10 x Clamper Screw
- 1 x GND Cable
- 1 x USB Touch Cable
- 1 x VGA Cable
- 7 x HDMI and DP Lockable Kit
- Country of Origin
- China
- Environmental Compliance
- Taiwan Restriction of Hazardous Substances (Taiwan RoHS)
