- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Packaged Quantity
- 1 / Unit
- Product Type
- Barcode Scanner
- Technical Information
- Connectivity Technology
- Cable
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
Linear:
- Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 Databar, UPC-A, UPC E, UPC-A/EAN-13 with Extended coupon Code, Coupon GS1 Code 32(PARAF), EAN-UCC Emulation, GS1 Data bar
2D Stacked:
- Codablock A, Codablock F, PDF417, MicroPDF417
2D Matrix:
- Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible(Han Xin) code
Postal Codes:
- Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet
- Light Source
- LED
- Image Sensor Type
- CMOS
- Scanning Distance
- 14.96"
- Field of View (Horizontal)
- 38°
- Field of View (Vertical)
- 29°
- Reading Angle (Skew)
- 45°
- Reading Angle (Pitch)
- 45°
- Reading Angle (Roll)
- 360°
- Motion Tolerance
- 4 in/s
- Minimum Print Contrast
- 35%
- Minimum Element Resolution (Code 39)
- 5 mil
- Maximum Element Resolution (Code 39)
- 20 mil
- Minimum Element Resolution (DataMatrix)
- 10 mil
- Minimum Element Resolution (PDF417)
- 6.7 mil
- Image Sensor Resolution
- 640 x 480
- Illumination Type
- LED
- Illumination Color
- White
- Interfaces/Ports
- Host Interface
- USB
- Environmental Conditions
- Operating Temperature
- 32°F (0°C) to 104°F (40°C)
- Miscellaneous
- Compatibility
Advantech UTC-510 Series
- Platform Supported
- Windows
