- General Information
- Manufacturer
- Allied Telesis, Inc
- Manufacturer Website Address
- http://www.alliedtelesis.com
- Brand Name
- Allied Telesis
- Product Series
- GS950 PS
- Product Type
- Ethernet Switch
The Allied Telesis GS950 PS Series of WebSmart network switches features PoE+ for connectivity with security cameras, VoIP phones, RFID readers and wireless access points. A cost-effective solution for SMB, retail stores and at the edge of the network.
Ease of Management and High Performance
These advanced Allied Telesis WebSmart switches integrate the simplicity of unmanaged switches with the performance and reliability of managed switches to provide an inexpensive yet secure and reliable solution for users to integrate management at the edge of their networks. With a user-friendly web-based management, the GS950 Series is an ideal option for integrating simple management and security into a network solution.
- Interfaces/Ports
- Total Number of Network Ports
- 10
- Token Ring Port
- No
- LRE Port
- No
- Bypass
- No
- Number of PoE+ (RJ-45) Ports
- 10
- Port/Expansion Slot Details
- 10 x Gigabit Ethernet Network
- 2 x Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- I/O Expansions
- Total Number of Expansion Slots
- 2.0
- Expansion Slot Type
- SFP
- Shared SFP Slot
- Yes
- Number of SFP Slots
- 2
- Network & Communication
- Layer Supported
- 2
- Management & Protocols
- Manageable
- Yes
- Management
- Web-based Management
- DHCP
- VLAN
- QoS
- SNMP v1, v2c, v3
- Syslog
- RMON 1, 2, 3, 9
- MIB II
- Memory
- Standard Memory
- 64 MB
- Memory Technology
- DRAM
- Flash Memory
- 16 MB
- Reliability
- MTBF
- 263000 Hour
- Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Rack-mountable
- Desktop
- Wall Mountable
- Height
- 1.7"
- Width
- 13"
- Depth
- 7.9"
- Weight (Approximate)
- 4.19 lb
- Miscellaneous
- Country of Origin
- China
