- General Information
- Manufacturer
- Hikvision
- Manufacturer Website Address
- http://www.hikvision.com
- Brand Name
- Hikvision
- Product Type
- Network Camera
- Technical Information
- Night Vision
- Yes
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/3"
- Color Supported
- Color
- Field of View
- 45.3°
- Effective Camera Resolution
- 1.3 Megapixel
- Video
- Video Formats
- H.264
- MJPEG
- MPEG-4
- Maximum Video Resolution
- 1280 x 960
- Maximum Frame Rate
- 30 fps
- Image
- Maximum Image Resolution
- 1280 x 960
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 6 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/2
- Exposure
- Shortest Shutter Speed
- 1/100000 Second
- Longest Shutter Speed
- 1/25 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet
- Yes
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP/IP
- HTTP
- DHCP
- RTP
- RTSP
- PPPoE
- SMTP
- NTP
- SNMP
- HTTPS
- FTP
- 802.1X
- QoS
- DNS
- DDNS
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 5 W
- Input Voltage
- 12 V DC
- Physical Characteristics
- Form Factor
- Bullet
- Color Family
- White
- Product Color
- White
- Height
- 3"
- Width
- 2.4"
- Depth
- 5.5"
- Diameter
- 2.4"
- Weight (Approximate)
- 10.58 oz
- Environmental Conditions
- Maximum Operating Temperature
- 140°F (60°C)
- Miscellaneous
- Features
- Day/Night
- Digital Noise Reduction
- Indoor/Outdoor
- Outdoor
- System Requirements
- Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bit
- CPU: Intel Pentium IV 3.0 GHz or higher
- RAM: 1G or higher
- Display: 1024×768 resolution or higher
- Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version Mozilla Firefox 3.5 and above version and Google Chrome 8 and above versions
- Certifications & Standards
- IP66
- CE
- FCC
- Ingress Protection Rating
- IP66
- Security Features
- User Authentication
- Watermark
- Platform Supported
- PC
- Environmentally Friendly
- Yes
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS)
