- General Information
- Manufacturer
- Hikvision
- Manufacturer Website Address
- http://www.hikvision.com
- Brand Name
- Hikvision
- Product Type
- Video Door Phone Master Station
- Display & Graphics
- Screen Size
- 7"
- Display Screen Type
- TFT LCD
- Screen Resolution
- 1024 x 600
- Touchscreen
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Consumption
- 5 W
- Physical Characteristics
- Height
- 55.1"
- Width
- 78.7"
- Depth
- 6.1"
- Miscellaneous
- Application/Usage
- Indoor
- Compatibility
- Hikvision Face Recognition Terminals:
- DS-K1T671TM-3XF
- DS-K1T671TM-3XF
- Additional Information
System Parameters:
- Memory: 1GB
- Flash: 4GB
- Operation System: Android 5.1
Network parameters
- Network protocol: TCP/IP, Private SIP, RTSP
- Wired network interface: 10/100 Mbps self-adaptive
- Wireless network interface: Wi-Fi 802.11 b/g/n
Audio parameters
- Audio input: Built-in omnidirectional microphone
- Audio output: Built-in loudspeaker
- Volume: Adjustable
- Audio compression standard: G.711 U, G.711 A
General
- Working temperature-10 °C to 50 °C (14 °F to 122 °F)
- Working humidity10% to 90%
Display Parameters
- Display Screen: 7-inch colorful TFT touch screen
- Display Resolution: 1024 × 600
- Operation Method: Capacitive touch screen
Device interfaces
- TF cardBuilt-in 32 G TF card
Alarm Parameters
- Alarm Input: 8
Device Interfaces
- Network Interface: RJ45
- RS-485: 1
- Debug: 1
