Artistic Space beyond Display, LG Wallpaper OLED Signage
This sophisticated wallpaper OLED signage achieves the best possible picture quality, concealing its presence by blending in with the wall. Minimal space is required for installation, which simplifies the construction process. The luxurious atmosphere generated with this signage will provide customers with an extraordinary experience, making them feel like VIPs.
UNRIVALED PICTURE QUALITY
Absolute Black
Equipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.
UNRIVALED PICTURE QUALITY
Rich Color
LG OLED Signage provides richness in all colors, bringing colors to life with great accuracy and vividness.
ULTIMATE ELEGANCE OF DESIGN
Splendid Design
LG's OLED technology unlocks the new worlds of design flexibility with unbelievably lightweight and slim display. The advantages the OLED display brings are countless from the easier installation to a sleek look.
ULTIMATE ELEGANCE OF DESIGN
Hide in Plain Sight
The subtle edge of the wallpaper OLED totally blends in with the wall, giving audiences the sensation that content is being played directly within the wall itself. Integrating with and adding to a luxurious interior design, the wallpaper OLED is an effective method for delivering advertisements and information.
REALIZING AN IMMERSIVE VIEW
N×N Expandable Screen Size
By tiling up displays horizontally and vertically, the screen size can be as large as users want. Expansive, large screens are more effective at moving viewers by providing an incredibly immersive viewing experience.
REALIZING AN IMMERSIVE VIEW
LAN Daisy Chain Management
A LAN daisy chain is supported, allowing you to execute commands to control and monitor the displays and even update their firmware.
EASY INSTALLATION
Wall Fixers Optimized for Simple Tiling
The overall installation process of the wallpaper OLED has gotten much easier. Once the dedicated wall fixers are driven into a wall, a display can be easily hung on them. Video wall tiling has become more convenient, thanks to its front installation feature, which departs from the conventional side-sliding method.
EASY INSTALLATION
Enhanced Flexibility of Cables
As a result of in-depth consideration of usage scenarios, improvements have been made to the flexibility of common cables connecting the display to the signage box. These new cables are pliable enough to be easily embedded in a wall or other structures.
- General Information
- Manufacturer
- LG Electronics
- Manufacturer Website Address
- https://solutions.lg.com/us
- Brand Name
- LG
- Product Series
- EJ5G
- Product Type
- Digital Signage Display
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Features
- TileMatrix Support
- Wake on LAN (WOL)
- Crestron Inside
- FailOver
- Temperature Sensor
- Video Wall Compatible
- Yes
- Bezel Width
- 35.4 mil
- Bezel Width (Bottom)
- 0.21"
- Bezel Width (Top)
- 0.21"
- Bezel Width (Left)
- 0.21"
- Bezel Width (Right)
- 0.43"
- HDCP Version
- 1.3
- Surface Hardness
- 2H
- Panel Technology
- OLED
- Operation Hours
- 18 Hours/7 Days
- Memory
- Standard Memory
- 16 GB
- Display & Graphics
- Viewable Screen Size
- 55"
- Display Screen Type
- OLED
- Display Resolution
- 1920 x 1080
- Response Time
- 1 ms
- Aspect Ratio
- 16:9
- Backlight Technology
- LED
- HDCP Supported
- Yes
- Orientation
- Landscape/Portrait
- Video
- Scan Format
- 1080p
- Standard Refresh Rate
- 120 Hz
- Dynamic Contrast Ratio
- 150,000:1
- Color Depth
- 10-bit
- Brightness
- 400 Nit
- Color Gamut
- 120% BT.709
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Audio Line Out
- Yes
- Serial
- Yes
- Number of USB 2.0 Ports
- 2
- Number of DisplayPorts
- 1
- DisplayPort Output
- Yes
- Number of Audio Line Out
- 1
- Number of DisplayPort Outputs
- 1
- Software
- Operating System
- webOS 4.0
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Power Consumption (DPM)
- 3W
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Minimum Operating Humidity
- 10%
- Maximum Operating Humidity
- 80%
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Bezel Color
- Black
- Mount Type
- Wall Mountable
- Height
- 27.4"
- Width
- 48"
- Depth
- 0.2"
- Weight (Approximate)
- 14.60 lb
- Miscellaneous
- Package Contents
- 55EJ5G-B Digital Signage Display
- Remote Control (battery 2ea)
- Power Cord
- QSG
- IR receiver
- Regulation Book
- Phone to RS232C Gender
- RS232 cable (4p-4p)
- FFC Cables (1600mm x 4ea for connection between panel and Signage Box)
- DP Cable
- LAN Cable
- LC (VLC Cable)
- Wall Fixer (4ea)
- Wall Fixer Install Guide
- Install Guide Sheet (2ea)
- Tape (10ea for Cabling/2ea for Dustproof)
- Screws (M4xL25, 10ea/M3xL5.5, 8ea)
- Additional Information
- Crestron Inside : Yes
- Certifications & Standards
- Class "A" CE (Regulatory) IEC/EN/UL 60950-1 (EMC)
- Environmentally Friendly
- Yes
- Energy Efficiency Compliance
- Energy-related Products Directive (ErP)
