The Server Technology® Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral and POPS® technology provides accurate measurement of current (billing-grade), voltage, active power, apparent power, power factor, crest factor, and accumulated energy at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The Switched POPS "Master" PDU can be connected to a Switched POPS "Link" PDU to extend the network access to the redundant or secondary power feed.
- General Information
- Manufacturer
- Legrand Group
- Manufacturer Website Address
- http://www.servertech.com
- Brand Name
- Server Technology
- Product Series
- PRO1
- Product Type
- PDU
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- PDU Type
- Switched
- Phase
- Three Phase
- Plug/Connector Type
- CS8365 3P+G 50A
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 18 x IEC 60320 C13
- 6 x IEC 60320 C19
- Protection Type
- Fuse
- Power Description
- Input Voltage
- 230 V AC
- Output Voltage
- 208 V AC
- Power Rating (Watt)
- 14.40 kW
- Input Current
- 50 A
- Management
- Management
- SSH
- SMTP
- Syslog
- HTTP/HTTPS
- TLSv1.2
- SSHv2
- Telnet
- SNMPv2c and v3 (GET, SET, Traps)
- IPv4 and IPv6
- LDAPv3/LDAPS
- TACACS+
- RADIUS
- FTP/SFTP
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Mount Type
- Rack-mountable
- Height
- 70"
- Width
- 1.8"
- Depth
- 3.5"
- Miscellaneous
- Country of Origin
- United States
