- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Product Line
- SuperChassis
- Product Series
- SC745
- Product Type
- Server Case
Tower / 4U SuperChassis 745
Supermicro's SC745 Chassis series is optimized for the latest Intel® Xeon® processor 5500 series (Nehalem) and is also compatible with previous generation Intel and AMD dual processor-based motherboards. Utilizing redundant, high-efficiency power supplies (85% and up) with Gold Level 1200W option, and 8 hot-swap 3.5" drive bays, this chassis offers reliable performance with problem-free maintenance. Designed with 100% cooling redundancy** via a combination of high-performance fans and adjustable air-shroud capable of fitting any generation motherboard, the SC745 minimizes the probability of system downtime or performance degradation from thermal-related issues. With 90-degree rotatable drive bay module, 7 tool-less expansion slots, and 6-Pin power connectors supporting up to 3 high-end graphics cards, the SC745 supports up to 3 GPUs, and it is quick to configure and easy to operate.
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Motherboard Supported
- EATX
- ATX
- Number of Fans Supported
- 5
- Number of Fans Installed
- 5
- Bays
- Number of External 5.25" Bays
- 3
- Number of Internal 3.5" Bays
- 8
- Number of Total Expansion Bays
- 11
- I/O Expansions
- Total Number of Expansion Slots
- 7
- Interfaces/Ports
- Total Number of USB Ports
- 2
- Front USB
- Yes
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Power Supply Wattage
- 1280 W
- Redundant Power Supply
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Compatible Rack Unit
- 4U
- Form Factor
- Tower
- Height
- 17.2"
- Width
- 7"
- Depth
- 25.5"
- Miscellaneous
- Package Contents
- SuperChassis SC745BTQ-R1K28B System Cabinet
- 1 x CSE-SAS-743TQ-O-P
- 1 x 8pin to 8pin ribbon cable with tube for SGPIO, 40cm, PBF
- 4 x SATA CABLE 61CM FLAT S-S PBF
- 1 x POWER DISTRIBUTOR FOR SC747 W/ GRAPHIC OUTPUT FEATURE
- 1 x SC745 Intel DP X9, X8 PC air shroud 1368x13/12x13MB
- 1 x Front Control Cable Round 16pin to 16pin Ribbon 20inch (50cm)
- 3 x 4 TO 4 PIN MIDDLE FAN POWER EXTENSION, 200MM (PWM)
- 8 x Black Hot-swap 3.5inch HDD Tray (w/o logo)
- 1 x Plastic feet (4 pcs set) for 4U tower chassis, black color
