Buy Supermicro C9X299-PGF Desktop Motherboard - Intel X299 Chipset - Socket R4 LGA-2066 - Intel Optane Memory Ready - ATX

Supermicro C9X299-PGF Desktop Motherboard - Intel X299 Chipset - Socket R4 LGA-2066 - Intel Optane Memory Ready - ATX

Part: 2059092
Model: MBD-C9X299-PGF-B

$525.00

Availability

In Stock

Core™ X-Series Processor Based Motherboards

X299 chipset / Socket R4 Boards

Supermicro's new ATX form factor motherboards using Intel® X299 Express Chipset supports Intel® Core™ i9/i7/i5 X-Series Processors. The X299 new platform supports overclocking of CPU and Memory with increased performance, with SuperO Booster and Intel XTU/management tool. Ideal applications include workstation and high frequency trading.

General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Packaged Quantity
- 1
- Package Type
- Bulk
- Product Type
- Desktop Motherboard

Warranty
- Limited Warranty
- 1 Year

Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- X299
- Total Processor Supported
- 1
- Processor Socket
- Socket R4 LGA-2066
- Processor Supported
- Core X-Series

Memory
- Number of Memory Slots
- 8
- Memory Form Factor
- - DIMM
  UDIMM
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 1866 MHz
- 2666 MHz
- 2400 MHz
- 2133 MHz
- 1600 MHz
- Intel Optane Memory Ready
- Yes

I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 10
- 5
- 1
- 0

Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Model
- AST2500

Network & Communication
- Gigabit Ethernet
- Yes

I/O Expansions
- Total Number of Expansion Slots
- 5
- Total Number of PCI Express Slots
- 5
- Number of PCI Express x1 Slots
- 1
- Number of PCI Express x16 Slots
- 4

Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 3.0 Ports
- 2
- Number of USB 3.1 Ports
- 4
- VGA
- Yes

Onboard Interfaces
- Number of SATA Interfaces
- 6
- Number of M.2 Interfaces
- 2
- Total Number of Onboard USB Ports
- 6
- Number of Onboard USB 3.0 Ports
- 2

Physical Characteristics
- Form Factor
- ATX
- Width
- 12"
- Depth
- 9.6"

Miscellaneous
- Package Contents
- - C9X299-PGF Desktop Motherboard
  - 2 x SATA Cable
  - 1 x IO Shield
- Compatibility
- SuperChassis:
  - SCGS5A-753K
  - SCGS5A-753R
  - SC732D3-903B
  - SC732D3-1200B
  - SC743AC-668B
  - SC743AC-1200B-SQ
- Environmentally Friendly
- Yes
- Environmental Compliance
- - Waste Electrical and Electronic Equipment Directive (WEEE)
  Restriction of Hazardous Substances (RoHS)
