- General Information
- Manufacturer
- Transition Networks, Inc
- Manufacturer Website Address
- http://www.transition.com
- Brand Name
- Transition Networks
- Product Line
- ION
- Product Series
- S6110
- Product Type
- Data Multiplexer
The ION 4xT1/E1/J1 copper to fiber network interface device (NID) provides a solution for those users that need to extend multiple T1/E1 connections over fiber.
The ION 4xT1/E1/J1 supports Small Form Pluggable (SFP) transceivers to support a variety of fiber types, distances and wavelengths to provide maximum flexibility across a variety of network topologies.
The use of Coarse Wave Division Multiplexing (CWDM) SFPs can be utilized to further increase the bandwidth capacity of the fiber infrastructure.
- Warranty
- Limited Warranty
- Lifetime
- Interfaces/Ports
- Number of RJ-48 Ports
- 4
- Number of SC Ports
- 1
- SC Port Type
- Simplex
- Media & Performance
- Connectivity Technology
- Wired
- Media Type Supported
- Optical Fiber
- Ethernet Technology
- Fast Ethernet
- Network Technology Supported
- T1/E1/J1
- Maximum Data Transfer Rate
- 100 Mbit/s
- Power Description
- Input Voltage
- 12 V DC
- Physical Characteristics
- Form Factor
- Desktop
- Height
- 1.8"
- Width
- 3.7"
- Depth
- 6.5"
- Miscellaneous
- Certifications & Standards
- EN55022 Class A
- EN55024
- CE Mark
- 802.3
- 802.3u
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
