- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- Vertiv Liebert
- Product Series
- GXT4
- Product Type
- Double Conversion Online UPS
The Vertiv™ Liebert® GXT4 UPS, with a capacity of 700VA/630W, is a compact and reliable solution for maintaining the health and availability of your IT infrastructure. Using on-line, double-conversion technology, the Liebert GXT4 UPS protects equipment from the full range of power disturbances, including sags, surges and noise, without drawing on battery power, extending battery life and minimizing replacements. The UPS runs on 230V AC power and includes hot-swappable batteries as well as all hardware for installing it as a tower or in an equipment rack. It is ENERGY STAR® qualified and includes selectable eco-mode that enhances efficiency during off hours. With outstanding performance and reliability, the Liebert GXT4 is the UPS of choice for applications with zero tolerance for downtime.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Phase
- Single Phase
- Power Description
- Load Capacity (VA)
- 700 VA
- Load Capacity (Watt)
- 630 W
- Output Voltage
- 200 V AC
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- Battery Information
- Battery Characteristics
- Valve-regulated
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 11 Minute
- Typical Battery Recharge Time
- 3 Hour
- Hot Swappable
- Yes
- Physical Characteristics
- Height
- 3.4"
- Width
- 16.9"
- Depth
- 16.2"
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 40 lb
- Miscellaneous
- Package Contents
- GXT4-700RT230 700VA Tower/Rack Mountable UPS
- 10A IEC C13 C14 Output Cable-two, 2m (6-1/2 ft.) Long
- CEE 7/7 (Schuko) to IEC C13 Input Cord-one
- 2.5m (8-1/2 ft.) Long
- BS 1363 (UK) to IEC C13 Input Cord-one, 2.5m (8-1/2 ft.) Long
- Australian Type A to SAA Input Cord-one
- Terminal Block Communication Terminals
- Compact Disk with Liebert MultiLink Shutdown Software
- Configuration Program
- User Manual
- USB Cable-one, 1.2m (3.9 ft.) Long
- RS-232 Cable-one, 2m (6-1/2 ft) Long
- Cable Strain Relief-two Pieces
- Rack Rail Kit
- Plastic Tower Stand Sets-two (Four Pieces)
- Warnings, Safety Instructions Booklet and WEEE Recycling Sheet (ISO 14001 Compliance)
- Additional Information
- 2 Programmable Outlet Groups
- Eco Mode capable
- Configuration can be saved and uploaded to other models of same size & voltage
- Energy Star
- Yes
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
