The Advantech IDK-1115P series comes with a 15" industrial grade LCD display with Projected Capacitive touch. IDK-1115P series supports Projected Capacitive touch with low power consumption. IDK-1115P series is ideal for embedded applications which customers have maximum flexibility for mechanical design.
- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Type
- LED Touchscreen Monitor
- Technical Information
- Screen Size Class
- 15"
- Viewable Screen Size
- 15"
- Screen Mode
- XGA
- Response Time
- 23 ms
- Aspect Ratio
- 4:3
- Horizontal Viewing Angle
- 176°
- Vertical Viewing Angle
- 176°
- Backlight Technology
- LED
- Features
- Anti-reflective
- Video
- Maximum Resolution
- 1024 x 768
- Color Supported
- 16.7 Million Colors
- Native Contrast Ratio
- 2,500:1
- Brightness
- 500 Nit
- Touchscreen Information
- Touchscreen Type
- Projected Capacitive
- Interfaces/Ports
- USB
- Yes
- Environmental Conditions
- Operating Temperature Range
- -4°F (-20°C) to 158°F (70°C)
- Power Description
- Operating Power Consumption
- 12.80 W
- Physical Characteristics
- Height
- 10"
- Width
- 12.9"
- Depth
- 0.4"
- Weight (Approximate)
- 2.12 lb
