The Vertiv Geist Basic Rack PDU VP9562 is a 15A, 120V, basic 1U horizontal rack mount power distribution unit (PDU). It has 10 NEMA 5-15R receptacles and a NEMA 5-15P plug providing 1.4kW in power capacity. The Basic Rack PDU (rPDU) has a horizontal form factor taking up just 1U of space in a standard rack. It is perfect for tight spaces in edge locations and small IT environments. Every Vertiv Geist Basic Rack PDU is UL-listed and are not batch-tested. All models undergo rigorous individual tests for reliability and functionality before shipping.
- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- Vertiv Geist
- Product Series
- rPDUs
- Product Type
- PDU
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- PDU Type
- Basic
- Plug/Connector Type
- NEMA 5-15P
- Receptacle Type
- NEMA 5-15R
- Receptacle Detail
- 10 x NEMA 5-15R
- Power Description
- Input Voltage
- 120 V AC
- Power Rating (Watt)
- 1400 W
- Input Current
- 15 A
- Physical Characteristics
- Mounting Orientation
- Horizontal
- Mount Type
- Rack-mountable
- Rack Height
- 1U
- Height
- 1.7"
- Width
- 17"
- Length
- 3.8"
- Weight (Approximate)
- 6 lb
- Miscellaneous
- Country of Origin
- United States
